Description
Accessory : F024772 2.000 IN Cam Lock Coupling For Discharge Hose, 156340 2.000 IN Diameter X 25.000 FT Discharge Hose Assembly, 54923 HTMA Male Coupler, 54924 HTMA Female Coupler Capacity : Up To 275 GPM (1041 LPM) (At 7 GPM (27 LPM) And A 10.000 FT(3.000 MR) Head Height) Discharge Size : 2.000 IN (44.000 MM) NPT Female Flow Rate : 5 – 8 GPM (19 – 30 LPM) Height : 12.500 IN (318.000 MM) Over Handle Operating Pressure : 0 – 2000 PSI (0 – 138 BAR) Pressure Port : 9/16 – 18 SAE O-Ring Return Port : 3/4 – 16 SAE O-Ring Strainer : 2-5/8 IN X 5-58 IN (67.000 MMX 143.000 MM) – 3/8 IN (9.500MM) Openings Suction Size : 1-15/16 IN (49.000 MM) System : Open and Closed Center System Type : Compact, Water Weight : 9.000 LB (4.000 KG) Width : 7.500 IN (190.000 MM)
To view an Operator’s Manual Click Here
