Description
Accessory : 54923 HTMA Male Coupler, 54925 HTMA Female Coupler, 49314Heavy Duty 7/16 IN Hex By 1/2IN Square Drive Shank Adapter Accessory : NR1 Nut Runner With Adapter For 5/8 IN, 1/2 IN, 13/16 INAnd 1.000 IN Square Nuts Accessory : NR2 Nut Runner With Adapter For 1.000 IN, 1-1/8 IN An Capacity : 7/16 IN Flow Range : 4 – 10 GPM (15 – 38 LPM) Handle Type : Heat-Insulated Height : 10.600 IN (269.000 MM) Hydraulic System : Super Spool Selector For Either Open-Center Or Closed-Center Includes : 49314 Heavy Duty 1/2 IN Square Drive Adapter Length : 8.200 IN (208.000 MM) Operating Pressure : 1000 – 2000 PSI (69 – 140 BAR) Optimum Flow Range : 5 – 8 GPM (19 – 30 LPM) Pressure Port : 3/4 – 16 SAE O-Ring Return Port : 3/4 – 16 SAE O-Ring Torque Rating : 400 FT-LB At 8 GPM (542 N-M AT 30 LPM) Maximum, 400 FT-LB 8 GPM (542 N-M At 30 LPM) Minimum Weight : 7.700 LB (3.500 KG)
