Description
Accessory : NR1 Nut Runner With Adapter For 5/8”, 1/2”, 13/16” and 1.000” Square Nuts, NR2 Nut Runner With Adapter For 1.000”, 1-1/8” And 1-5/16” Square Nuts, 00376 Trigger Guard Kit For HW1 Or HW1V, 49314 Heavy Duty 7/16” Hex X 1/2” Square Drive Shank Capacity : 7/16 IN Hex Drive Size : 1/2 IN Flow Range : 4 – 12 GPM (15 – 46 LPM) Handle Type : Impact And Temperature Resistant Replaceable Polymer Grip Height : 11.000 IN Hydraulic System : Super Spool Selector For Open and Closed-Center Systems Includes : 7/16 Hex Quick-Change Chuck And 49314 Heavy-Duty Adapter IN Length : 8.200 IN Operating Pressure : 1000 – 2500 PSI (69 – 170 BAR) Optimum Flow Range : 5 – 8 GPM (19 – 30 LPM) Pressure Port : 9/16 – 18 SAE O-Ring Replacement : 54923 HTMA Male Coupler: HTMA, 3/4-16 SAE O-Ring Exterior Thread, 54925 HTMA Female Coupler: HTMA, 9/16-18 SAE O-Ring Exterior Thread Return Port : 3/4 – 16 SAE O-Ring Torque Rating : 500 FT-LB At 8 GPM (677 N-M At 30 LPM) Maximum, 500 FT-LB At 8 GPM (677 N-M At 30 LPM) Minimum Type : Hydraulic, High Torque
To view an Operator’s Manual Click Here
To view an Operator’s Manual Click Here
