Description
Accessory : F020198K UPC 41780 HTMA Male Coupler 3/8 IN NPTF Accessory : F020195K UPC 41777 HTMA Female Coupler 3/8 IN NPTF Air Flow : 2.8 CU FT/MIN (80 LPM) Air Pressure : 29 PSI (2 BAR) Blows Per Minute : 1400 BPM Maximum (Varies withRotation Speed) Chuck Size : 7/8 IN (22.000 MM) Diameter X4-1/4 IN (108 MM) Length Hydraulic Flow Range : 5 – 7 GPM (19 – 25 LPM) Hydraulic System : Open-Center Length : 25.000 IN (626.000 MM) Maximum Pressure : 3000 PSI (207 BAR) Operating Pressure : 1275 – 1700 PSI (88 – 118 BAR) Speed : 0 – 400 RPM Drill Rotation Type : Hydraulic Weight : 44.000 LB (20.000 KG) Whip Hoses : 3/8 IN NPTF X 12.000 IN (305.000 MM) Width : 16.000 IN (412.000 MM)
To view an Operator’s Manual Click Here
