Description
Amperage Measurement : 600, 6000μA; 60, 600mA; 6, 10A Battery : (1) 9 V Capacitance : 60, 600nF; 6, 60, 600μF; 6, 25 mF Conductance : 99.99 nS Display : Backlit LCD With Dual 10,000 Count Frequency Measurement : 15Hz- 50kHz Sine Wave, 5Hz – 1MHz Logic Level Square Wave Includes : (1) 9V Battery, Bead Temperature Probe (DM-820A, DM-830A Only, 400°F/204°C Max), Test Leads, Protective Boot, Carrying Case Measurement Category : CAT IV, 1000 V Replacement Part : TC-20 Carrying Case, TSG-3 Sure-Grip Test Leads, TPB Bead Temperature Probe (Included With DM-820A, DM-830A) Resistance Measurement : 600Ω; 6, 60, 600 kΩ; 6, 60 MΩ Standard : CAT IV, C/UL US Listed, TRUE RMS, CE Listed Temperature Rating : K Type, -58 To 1832°F (-50 To 1000°C) Type : Digital Voltage Measurement : 60, 600 mV, 9.999, 99.99, 999.9 V
To view an Operator’s Manual Click Here
To view an Operator’s Manual Click Here
