CRIMPING TOOL, DIELESS REMOTE

$3,467.60

HDE Direct contact voltage detection The TAG-200XMR is a multi-range direct contact voltage detector that determines if a conductor is energized within its specific voltage setting. Kit includes overhead probes, underground probe and carrying case. Direct contact solution to quickly test for the presence of voltage No on/off or range selector switches, always on. Clear indication of voltage detection with both audible and visual indications “All Check” self test system verifies proper operation TAG 200X series for system voltages up to 69KV line to line Versitle for overhead and underground applications Built in universal spline and shotgun stick attachments
To view more info on the Greenlee site Click Here

Description

Application : Remote Dieless Crimping Head (10K PSI) Capacity : 4 AWG – 1000 kcmil copper or 6 AWG -1000 kcmil aluminum Connector Type : 3/8” male screw-type coupler Crimp Cycle Time : 3 seconds Crimping Capacity : Refer to crimping chart in instruction manual Crimping Force : 24,000 (106 kN) Height : 2” (51mm) Includes : Heavy duty canvas bag Overall Length : 13” (330mm) Weight : 9.75 lbs. (4.42kg) Width : 3.75” (95mm)
To view an Operator’s Manual Click Here
To view a Brochure Click Here

Additional information

Weight 12.82 lbs
Dimensions 17.5 × 16.6 × 5.2 in
Catalog #

RK12ID

Material #

52065523

UPC/Ean #

7.8331E+11

Sold in Quantities of

1
