Description
Accessory : F020196K HTMA Female Coupler – 1/2 IN NPTF internal thread, F020197K HTMA Male Coupler – 1/2 IN NPTF internal thread Application : For Breaking Sidewalks And Curbs Or Driving Ground Rod, AndFor Other Small Demolition Jobs Blow Energy : 63.000 FT-LB (85 J) Blows Per Minute : 2160 BPM Handle Type : Cushioned/Spring-Dampened Hydraulic System : Open-Center Length : 26.500 IN (682.000 MM) Maximum Pressure : 2300 PSI (160 BAR) Oil Flow : 5 – 8 GPM (19 – 30 LPM) Operating Pressure : 1500 – 1800 PSI (105 – 125 BAR) Pressure And Return Ports : 1/2 IN BSP Shank Size : 1.000 IN Diameter X 4-1/4 IN Length Sound Power Level : LWA=109 DB Vibration Level : 11.400 M/S2/5.300 M/S2 Weight : 47.000 LB (21.300 KG) Whip Hoses : 1/2 IN NPTF X 12.000 IN (305.000 MM)
To view an Operator’s Manual Click Here
To view an Operator’s Manual Click Here
